Type:PCB Gate Drive Board
Model Number:ABX-1336-BDB-SP6A
Power Rating:5kW
Operating Voltage:DC 24V to 600V
Operating Current:Up to 150A
Input Interface:TTL, CMOS, and Schmitt Trigger compatible
Output Configuration:Opto-isolated outputs
Temperature Range:-40°C to +85°C
Protection Features:Over-voltage, over-current, short-circuit, and thermal protection
The ABB 1336-BDB-SP6A PCB Gate Drive Board Kit is engineered to deliver exceptional performance in harsh industrial environments. It ensures reliable operation of power semiconductors in drives and motor control applications.
Featuring a compact design, this board is optimized for space efficiency without compromising on robustness or reliability. Its high current rating and wide voltage range make it suitable for a variety of industrial automation tasks.
Equipped with advanced signal processing capabilities, the 1336-BDB-SP6A supports both TTL and CMOS input signals, ensuring compatibility with a broad spectrum of control systems. The RS-485 Modbus RTU interface facilitates seamless integration with networked industrial systems.
Withstanding extreme temperatures from -40°C to +70°C, this board is built to endure challenging conditions encountered in various industrial sectors, including manufacturing, automotive, and energy production.
Designed with user-friendliness in mind, the ABB 1336-BDB-SP6A PCB Gate Drive Board Kit includes comprehensive documentation and support, making installation and maintenance straightforward even for those new to industrial automation components.
