ABB 5SHX1960L0006 3BHB016120R0002 Product Introduction
Product Description
The ABB 5SHX1960L0006 3BHB016120R0002 is a high-performance IGBT (Insulated Gate Bipolar Transistor) module, designed for efficient power conversion and control in industrial applications. It serves as a critical component in inverters, converters, and motor drives, enabling precise regulation of electrical power in systems such as renewable energy installations (solar and wind), industrial machinery, and power distribution networks. With advanced semiconductor technology, this module delivers fast switching speeds, low power loss, and excellent thermal conductivity, ensuring stable operation even under high-load conditions. Its robust construction allows it to withstand harsh industrial environments, contributing to extended service life and reduced maintenance requirements.
Technical Parameters
- Collector-Emitter Voltage (VCE): 1700 V, providing high voltage handling capability for demanding applications.
- Continuous Collector Current (IC): 190 A, suitable for medium to high power systems.
- Pulsed Collector Current (ICM): 380 A, capable of managing short-term peak current loads.
- Switching Frequency: Up to 8 kHz, ensuring efficient power conversion with minimal losses.
- Forward Voltage Drop (VCE(sat)): Typ 2.2 V at 190 A, minimizing energy dissipation during operation.
- Operating Junction Temperature (TJ): -40 ~ 150 °C, maintaining performance across a wide thermal range.
- Storage Temperature Range: -55 ~ 150 °C, preserving integrity when not in use.
- Isolation Voltage (Viso): 4200 V RMS, ensuring safe electrical isolation between components.
- Thermal Resistance (Rth(j-c)): 0.12 K/W, facilitating effective heat dissipation to prevent overheating.
- Weight: Approximately 0.8 kg, lightweight for easy installation and handling.
- Dimensions (L × W × H): 140 mm × 90 mm × 45 mm, compact for integration into various systems.
- Terminal Type: Press-fit terminals, ensuring secure and low-resistance electrical connections.
The ABB 5SHX1960L0006 3BHB016120R0002 is available for global sale, covering all major industrial regions. Orders are processed promptly, with delivery guaranteed within 3 days, ensuring quick integration into your power electronic systems to minimize operational delays.
