Board Type:Profibus-DP/PDNet Expansion
Communication Interface:Profinet
Number of Inputs/Outputs:32 Inputs / 32 Outputs
Operating Voltage:DC 24V
Dimensions (W x H x D):120mm x 110mm x 67mm
Weight:0.3kg
Temperature Range:-20°C to +60°C
Enclosure Rating:IP20
Connection Ports:RS485/Profinet
Protocol Support:Profinet, Modbus TCP/IP, DeviceNet
Engineered for precision and reliability, the ABB DSQC688 is a pivotal component for optimizing industrial automation processes. This high-performance board seamlessly integrates with a variety of industrial control systems, enhancing operational efficiency through its robust I/O channels and efficient data processing capabilities.
Featuring a processor speed of up to 1 MHz, the DSQC688 ensures swift response times and accurate control over industrial machinery. Its 16 digital input and 8 digital output channels provide ample flexibility for diverse applications, allowing seamless communication between various devices within the system.
Designed for optimal performance in a wide range of environments, this board operates reliably from -20°C to +60°C, ensuring continuous functionality regardless of the ambient conditions. Its power consumption of max. 10 W ensures energy efficiency without compromising on performance.
The ABB DSQC688 supports the industry-standard Profinet protocol, facilitating seamless integration with Profinet-enabled devices. This compatibility simplifies the setup process and enhances interoperability across different automation components.
For ease of installation and maintenance, the DSQC688 is equipped with a panel mount design. This feature not only streamlines the assembly process but also allows for quick access to the board for troubleshooting or updates, contributing to a more streamlined workflow in industrial settings.
