ABB DSTC176: Extender Unit for Bus Termination, Bus Extension, Control System Modules

Manufacturer:ABB

Model:DSTC176

Series:Bus Extension

Module Category:Terminator Unit

Bus Compatibility:Supports various industrial buses including DeviceNet, CAN, and EtherCAT

Signal Integrity:Enhances signal quality at bus terminations

Environmental Rating:IP20 rated for indoor use

Electrical Rating:Up to 24 VDC supply voltage

Current Handling:Maximum current up to 2 A

Dimensions:100 mm x 100 mm x 25 mm

Weight:0.25 kg

Connector Type:M12 connector compatible with industry-standard wiring

Operating Temperature Range:-25°C to +60°C

    The ABB DSTC176 Terminator Unit is engineered to enhance the performance of bus systems by terminating the end of the bus, thereby reducing signal reflections and improving data transmission accuracy.

    Crafted from high-quality materials for durability and reliability, this terminator unit ensures stable operation under various environmental conditions, making it suitable for use in harsh industrial environments.

    With its compact design and lightweight construction, the DSTC176 is easy to install and integrates seamlessly with existing ABB and third-party bus systems.

    This terminator unit supports both RS485 and CAN protocols, providing flexibility in application scenarios and enabling seamless communication across diverse industrial control systems.

    Featuring low power consumption, the DSTC176 Terminator Unit offers energy-efficient performance without compromising on functionality or quality.
