ABB PDB-02 3HNA023093-001: Thermocouple/mV Input Module

Operating Temperature Range:-40°C to +85°C

Power Consumption:Max 2.5 W

Input Signal Types:Thermocouple (K, J, E, T, R, S, B, N) & mV

Output Type:Digital

Accuracy:±0.5% of full scale

Sampling Rate:Up to 1 kHz

Relay Output:1 SPDT relay contact, 24 VDC, 1 A

    The ABB PDB-02 3HNA023093-001 Thermocouple/mV Input Module is engineered to deliver unparalleled precision and reliability in industrial temperature measurement. This compact yet robust module seamlessly integrates with ABB‘s comprehensive range of PLC systems, enhancing system performance with its high-resolution signal processing capabilities.

    Designed with a wide operating temperature range from -20°C to +55°C, it ensures continuous and accurate operation in various industrial environments. The module supports a variety of thermocouple types including J, K, T, E, R, S, and B, alongside versatile millivolt inputs, catering to a broad spectrum of measurement needs.

    Featuring a 16-bit output resolution, this module guarantees exceptional accuracy and detail in data acquisition. It consumes a maximum of 50mA at 24V DC supply voltage, ensuring efficient power usage without compromising on performance. The module’s lightweight design and compact size facilitate easy installation and integration into existing systems, minimizing space requirements.

    Equipped with advanced signal conditioning technology, the ABB PDB-02 3HNA023093-001 Thermocouple/mV Input Module is capable of handling harsh industrial conditions with ease. Its durability and reliability make it an ideal choice for applications requiring long-term stability and maintenance-free operation.

    To further enhance user convenience, the module offers seamless compatibility with industry-standard communication protocols, allowing for straightforward connection to ABB‘s PLCs and other compatible systems. With its comprehensive feature set and superior performance, the ABB PDB-02 3HNA023093-001 Thermocouple/mV Input Module stands as a reliable solution for industrial temperature measurement.
