ABB SYN5202a-Z,V221 3BHB006715R0221 Product Introduction
Product Description
The ABB SYN5202a-Z,V221 3BHB006715R0221 is an advanced synchronization module, tailored for precise coordination of generators and power sources in medium to large-scale power systems. It specializes in aligning key electrical parameters—including frequency, voltage, and phase—between generators and the grid or other generators, ensuring smooth parallel operation and preventing disruptions to power supply. This module is widely utilized in power plants, industrial cogeneration facilities, and renewable energy installations (such as wind farms and solar parks), where reliable synchronization is critical to maintaining grid stability, reducing equipment stress, and optimizing energy distribution. Equipped with high-speed processing and accurate measurement technology, it responds swiftly to dynamic changes in system conditions, supporting seamless integration into complex power networks while maintaining consistent performance in harsh industrial environments.
Technical Parameters
- Synchronization Accuracy: Frequency mismatch ≤ ±0.01 Hz, phase angle mismatch ≤ ±0.5°, ensuring ultra-precise alignment.
- Input Voltage Range: 100 ~ 690 V AC (line voltage), compatible with a broad range of generator and grid voltage levels.
- Frequency Measurement Range: 45 ~ 65 Hz, adaptable to global power system frequencies.
- Response Time: ≤ 8 ms, enabling rapid adjustment to sudden changes in system conditions.
- Operating Voltage: 24 V DC ± 15%, compatible with standard industrial control power supplies.
- Power Consumption: ≤ 12 W, ensuring energy-efficient operation.
- Operating Temperature Range: -20 ~ 70 °C, suitable for extreme industrial environments.
- Storage Temperature Range: -40 ~ 85 °C, maintaining integrity during storage and transportation.
- Relative Humidity: 5% ~ 95% (non-condensing), resistant to moisture-related issues.
- Communication Interfaces: 1 x Ethernet port (Modbus TCP/IP), 1 x RS485 port (Modbus RTU), facilitating seamless data exchange with control systems.
- Output Signals: 6 x relay outputs (NO/NC, 250 V AC, 8 A), for controlling synchronization contactors, alarms, and auxiliary devices.
- Dimensions (L × W × H): 150 mm × 110 mm × 65 mm, compact for easy installation in control cabinets.
- Weight: Approximately 400 g, lightweight for convenient handling and mounting.
- Mounting Type: DIN rail mounting, compatible with standard industrial mounting systems.
- Certifications: IEC 61010, CE, UL, meeting international safety and performance standards.
The ABB SYN5202a-Z,V221 3BHB006715R0221 is available for global sale, covering all major power generation and distribution markets. Orders are processed efficiently, with delivery guaranteed within 3 days, ensuring timely integration into your power systems to minimize operational delays.
