Allen Bradley 1746-NO41 SLC 500 Output Module: Efficient Control for Industrial Automation

Model Type:SLC 500

Model Number:1746-NO41

Manufacturer:Allen Bradley

Output Channels:Up to 32

Output Voltage Range:5 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capacity:1 MA per channel

Current Rating:Continuous current per output: 0.25 A at 60°C, continuous current per module: 8 A at 60°C

Isolation:Communication circuits: 500 VDC, backplane: 1500 VAC

Enclosure Type:Open type

Mounting Method:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95% RH

Input Common Mode Voltage Range:-20 to 20 V

Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS (maximum)

Input Range:-20 to 20 mA

Absolute Input Current:-30 to 30 mA (maximum)

Overvoltage Protection:7.5 VAC RMS

    The Allen Bradley SLC 500 NO41 Output Module is designed for seamless integration into complex industrial control systems, ensuring reliable and efficient operation under demanding conditions.

    Equipped with advanced processing capabilities, this module delivers precise control over up to 4192 outputs, facilitating sophisticated automation tasks.

    With its extensive memory capacity and support for up to 4096 input signals, the NO41 Output Module provides ample resources for managing intricate system configurations.

    Featuring built-in Ethernet/IP support alongside compatibility with ControlNet, DeviceNet, and Universal Remote I/O links, this module ensures flexible connectivity and enhanced system interoperability.

    Robust and versatile, it supports various communication protocols, including DH+, DH-485, and RS-232, offering extensive customization options to fit diverse application requirements.

    Operational within a wide temperature range of 0 to 60°C and withstands high humidity levels, this module is engineered for reliability and durability in harsh industrial settings.
