Allen-Bradley 1756-EN2T Ethernet Module, ControlLogix Communication Bridge

Model Type:High Capacity IP Module

Manufacturer:Allen Bradley

Communication Module:ControlLogix®

Power Supply:3 MA at 24 VDC

Mounting:Chassis

Communication Speed:10/100 MBPS

Communication Protocol:Ethernet/IP Bridge

Enclosure Type:Open Type

Connection Cables:802.3 Compliant Shielded or Unshielded Twisted Pair

Temperature Rating:0 – 60 DEG C

Power Dissipation:5.1 W

Isolation:30 V Continuous

Environmental Conditions:5 – 95% Non-Condensing Relative Humidity

Vibration Resistance:2 G

Shock Resistance:30 G

Interface:Ethernet

USB Port:Not Available

    The Allen-Bradley 1756-EN2T Ethernet Module is engineered for advanced industrial automation environments, providing robust connectivity solutions with its Ethernet/IP bridge technology. This module is seamlessly integrated with ControlLogix systems, enabling smooth data transfer and communication across diverse industrial applications.

    Featuring a high capacity IP module design, it ensures reliable operation within a wide temperature range from 0 to 60 degrees Celsius, meeting the stringent requirements of industrial settings.

    With a power supply of 3 MA at 24 VDC, the module supports efficient energy management and compatibility with various industrial power standards.

    The open type enclosure ensures durability and protection against environmental factors, while the support for shielded or unshielded twisted pair cables ensures flexible installation options.

    Equipped with advanced isolation capabilities, the 1756-EN2T ensures signal integrity and reliability even under challenging conditions. This makes it an ideal choice for industries requiring high levels of precision and safety.

    The module’s compatibility with diverse industrial applications showcases its versatility and adaptability, making it a valuable asset in the realm of modern industrial automation.
