FACTS F4-16AD-2 Analog Voltage Input Module

Module Type:Analog Voltage Input

Resolution:12-bit

Channels:16

Signal Compatibility:Single-ended, terminated into a single common

Supported Ranges:0 to 5 VDC, 0 to 10 VDC

Output Type:Voltage Sourcing

Maximum Output Current:10 mA

Power Consumption:80 mA @ 5 VDC, External power supply 21.6 to 26.4 VDC

Operating Temperature Range:-20°C to +55°C

Storage Conditions:Non-operating conditions (-40°C to +85°C)

    Engineered for precision and reliability, the F4-16AD-2 module excels in interfacing with a wide range of industrial equipment, facilitating accurate data acquisition and control.

    Each of the sixteen channels is designed to receive and convert analog voltage signals from various sensors and measurement devices into digital signals, making it an indispensable component in automation setups.

    The module’s compact design and high-resolution 12-bit conversion ensure minimal signal distortion and enhanced accuracy, contributing to the overall efficiency and dependability of industrial systems.

    Suitable for applications requiring precise voltage measurement, the F4-16AD-2 supports two selectable output ranges (0 to 5 VDC and 0 to 10 VDC), offering flexibility to match diverse operational needs.

    To ensure optimal performance and longevity, the F4-16AD-2 operates best in a climate-controlled environment and requires proper handling during installation and maintenance.
