ABB GDC801B101 3BHE051592R0101 Product Introduction
Product Description
The ABB GDC801B101 3BHE051592R0101 is a high-reliability digital control module, specifically designed for use in industrial automation and power generation systems. It functions as a key component in regulating and monitoring critical processes, such as turbine control, generator management, and industrial process automation. This module excels in processing real-time data from sensors and other field devices, executing predefined control logic, and sending precise commands to actuators to ensure stable and efficient operation. It is widely applied in power plants, oil and gas facilities, and heavy manufacturing industries, where reliable control of complex machinery is essential for maintaining operational safety, optimizing performance, and minimizing downtime. With its robust construction and advanced circuitry, it can withstand harsh industrial environments, including temperature fluctuations, electrical noise, and vibration, delivering consistent performance in mission-critical applications.
Technical Parameters
- Processor: 32-bit microcontroller with a clock speed of 100 MHz, ensuring fast execution of control algorithms and real-time data processing.
- Memory: 512 KB RAM and 2 MB flash memory, providing sufficient space for program storage and data logging.
- Operating Voltage: 24 V DC ± 15%, compatible with standard industrial power supply systems.
- Power Consumption: Typical 15 W, balancing performance with energy efficiency.
- Digital Inputs: 16 channels, supporting dry contact or voltage signals (24 V DC), for monitoring statuses of field devices.
- Digital Outputs: 12 channels, relay-type outputs (NO/NC) with a maximum switching voltage of 250 V AC and current of 5 A, enabling control of actuators and alarms.
- Analog Inputs: 8 channels, 16-bit resolution, with a measurement range of 0 ~ 10 V DC or 4 ~ 20 mA, for precise monitoring of process variables like pressure and temperature.
- Communication Interfaces: 2 x RS485 ports (Modbus RTU) and 1 x Ethernet port (10/100 Mbps, Modbus TCP/IP), facilitating seamless data exchange with PLCs, SCADA systems, and other control components.
- Operating Temperature Range: -10 ~ 60 °C, suitable for harsh industrial working environments.
- Storage Temperature Range: -40 ~ 85 °C, maintaining integrity during storage and transportation.
- Relative Humidity: 5% ~ 95% (non-condensing), resistant to moisture-related issues.
- Isolation: 2.5 kV galvanic isolation between I/O channels and power supply, enhancing system safety and reducing electromagnetic interference.
- Dimensions (L × W × H): 120 mm × 100 mm × 50 mm, compact for easy installation in control cabinets.
- Weight: Approximately 300 g, lightweight for convenient handling and mounting.
- Mounting Type: DIN rail mounting, compatible with standard industrial mounting systems.
- Certifications: CE, UL, IEC 61010, meeting international safety and quality standards.
The ABB GDC801B101 3BHE051592R0101 is available for global sale, covering all major industrial regions. Orders are processed promptly, with delivery guaranteed within 3 days, ensuring quick integration into your automation systems to minimize operational delays.
