GE 369-HI-R-M-0-P-0-E - Advanced Motor Management Relay with Optional Metering & RTD Inputs

Control Power nominal:20 VA

Control Power maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:approx. 12 in H x 5 in W x 8 in L

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:Class I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Weight:approx. 4.5 kg

# of Digital/Switch Inputs:6 optically isolated

Maximum Ambient Humidity:Up to 95% non condensing

Maximum Altitude:2000 m (max)

Phase Current Inputs:1 A and 5 A secondary

The GE 369-HI-R-M-0-P-0-E is a cutting-edge motor management relay designed for medium-sized motors and their accompanying equipment.

It combines advanced monitoring features like waveform capture, event reporting, and data logging with comprehensive protection functions.

With its True RMS phase current input conversion and six optically isolated digital inputs, it ensures precise and reliable operation under varying conditions.

Ideal for industrial environments, this relay supports a wide range of control power inputs and is capable of operating in diverse humidity and altitude settings.

Its rugged design and robust insulation class make it suitable for heavy-duty applications where reliability and performance are paramount.
