Control Power:50-300 VDC / 40-265 VAC
Digital/Switch Inputs:6 optically isolated
Event Logs:Up to 512 recordable events
Communication Ports:RS232 port, RS485 port
Phase Current Inputs:1 A and 5 A secondary
Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels
Dimensions:Approximately 11.5 in H x 5.5 in W x 8.5 in L
Weight:Approximately 10 lbs
Maximum Altitude:2000 m (max)
Ambient Humidity:Up to 95% non-condensing
The GE 369-HI-R-M-0-D-0-E is designed for efficient motor management in industrial settings. It leverages advanced technology to provide critical insights into system performance through waveform capture, event reporting, and data logging. These features enable users to identify potential issues early and maintain optimal motor operation.
This relay supports up to 6 optically isolated digital and switch inputs, ensuring reliable signal transmission. It operates under a wide range of ambient humidity conditions, making it suitable for various environments. The control power specifications are optimized for energy efficiency and robust performance.
With dimensions of approximately 11.5 inches in height, 5.5 inches in width, and 8.5 inches in length, the 369-HI-R-M-0-D-0-E is compact yet robust, fitting well within most industrial enclosures. It includes a 3.15 A H 250 V fuse for added safety and protection.
The device is capable of handling phase currents up to 1 A and 5 A secondary, making it versatile for different motor types and applications. It supports recording up to the last 512 events, providing comprehensive historical data for analysis and troubleshooting.
Equipped with RS232 and RS485 communication ports, the 369-HI-R-M-0-D-0-E facilitates seamless integration with other systems and devices. The waveform capture feature captures 3 buffers containing 16 cycles of all current and voltage channels, offering detailed diagnostic data.
