Manufacturer:Mitsubishi Electric
Model:QM100DY-H
Series:MELSEC-Q
Module Type:Digital Input/Output
Input Points:16 points
Output Points:16 points
Voltage Rating:DC 24V
Current Rating:0.5A per point
Communication Interfaces:RS-485, Ethernet
Operating Temperature Range:-10°C to +60°C
Humidity Range:5% to 95% (non-condensing)
Power Consumption:2.2W
Dimensions:112mm x 95mm x 75mm (W x H x D)
Weight:0.2kg
Certifications:CE, UL, CSA
The MITSUBISHI QM100DY-H digital input/output module is designed to provide reliable and efficient operation in industrial environments. Its compact size makes it easy to integrate into existing systems without taking up valuable space. The uniform design ensures consistency across multiple modules, making installation and maintenance straightforward.
This module comes equipped with 16 digital input channels and 16 digital output channels, capable of handling voltages up to 24 VDC and currents up to 0.5 A per channel. The module supports multiple communication protocols, including MODBUS, PROFINET, and ETHERNET/IP, ensuring seamless integration with various industrial control systems.
Safety is a top priority, and the QM100DY-H includes a safe torque-off function (SIL3) as standard, providing peace of mind in critical applications. Additionally, the module features sensorless vector control for induction motors and permanent magnet motors, offering precise control over a wide frequency range up to 599 Hz.
Built-in features such as a braking chopper and coated circuit boards ensure durability and reliability in harsh environments. The module’s protection rating of IP65 provides excellent resistance to dust and water ingress, making it suitable for outdoor and industrial settings.
With its robust design and versatile functionality, the MITSUBISHI QM100DY-H is an essential component for any modern industrial automation system.
