National Instruments PCI-6224 Analog Input Module, High Precision, Versatile Data Acquisition

Data Rate:50 kS/s per channel

Resolution:14-bit

Channels:16 channels

Input Range:-10V to +10V

Sampling Frequency:Up to 250 kS/s

Accuracy:±0.02% + ±2 LSBs

Temperature Operation Range:-40°C to +85°C

Power Consumption:≤ 5 W

Interface:PCI Express

    The National Instruments PCI-6224 Analog Input Module is a robust and versatile solution for professionals seeking high-precision data acquisition. This module is equipped with 16 simultaneous, fully-differential, high-resolution 14-bit analog-to-digital converters (ADCs), enabling seamless integration into complex systems with its PCI Express interface. With a maximum data rate of 50 kS/s per channel, it ensures real-time performance and quick response times, critical for applications where timing and accuracy are paramount.

    Operating within an extensive temperature range from -40°C to +85°C, the PCI-6224 is designed for reliability in challenging environments, whether in the factory floor or outdoor testing conditions. Its low power consumption of ≤ 5 W makes it energy-efficient, reducing operational costs without compromising performance.

    Featuring an ultra-wide input range of -10V to +10V, this module can handle a broad spectrum of analog signals, making it suitable for various industries including manufacturing, automotive, and environmental monitoring. Its high accuracy of ±0.02% + ±2 LSBs ensures that every measurement is precise and reliable, crucial for scientific research and industrial quality control.

    Ease of use is a hallmark of National Instruments products. The PCI-6224 is compatible with a wide range of software tools, allowing for seamless integration into existing workflows. It supports National Instruments LabVIEW and other popular data acquisition software, facilitating setup, configuration, and analysis.

    Backed by National Instruments’ commitment to innovation and customer support, the PCI-6224 Analog Input Module comes with comprehensive documentation, tutorials, and access to a vast community of users. This ensures that you have all the resources needed to maximize the performance and efficiency of your data acquisition tasks.
