Omega Instruments DPF64-SQRT Thermocouple Signal Conditioner, Model-Specific, Analog-to-Digital Converter Module

Input Compatibility:Supports various thermocouple types (J, K, E, T, etc.)

Output Resolution:12-bit digital output

Operating Temperature Range:-40°C to +70°C

Power Consumption:Less than 10mA at full load

Data Rate:Up to 100 samples per second

Environmental Rating:IP65, dust and water resistant

Dimensions:100mm x 50mm x 25mm

    The Omega DPF64-SQRT is a high-performance process control module designed for accurate and consistent temperature monitoring and control across various industrial settings. Its exceptional precision, even within extreme temperatures, makes it an indispensable tool in industries requiring stringent thermal management.

    Featuring a wide operational range from -40°C to 150°C, the DPF64-SQRT ensures reliability in cold storage facilities, chemical processing plants, and other environments where temperature fluctuations are common. The device’s 0.01°C resolution and +/- 0.25°C accuracy at 25°C guarantee minimal error margins, critical for maintaining product quality and operational efficiency.

    Equipped with a fast response time of just one second, the DPF64-SQRT enables swift adjustments to maintain desired temperatures, enhancing process stability. Its flexible voltage range of 12V DC to 24V DC supports diverse power sources, ensuring compatibility across multiple systems.

    Offering versatile output types including 4-20mA, 0-10V, or relay output, the DPF64-SQRT facilitates seamless integration with existing control systems, providing both analog and digital communication options. Its Modbus RTU protocol further simplifies data exchange and system management.

    With an IP65 enclosure rating, the DPF64-SQRT is dustproof and splash-proof, suitable for use in harsh outdoor conditions or areas with frequent water exposure. Its compact dimensions of 90mm x 55mm x 25mm make it easy to install and integrate into tight spaces without compromising performance.

    Backed by Omega’s commitment to quality and customer support, the DPF64-SQRT comes with comprehensive documentation and technical assistance, ensuring users can easily implement and optimize its use for their specific applications.
