ABB PCD235A101 3BHE032025R0101 Product Introduction
Product Description
The ABB PCD235A101 3BHE032025R0101 is a high-performance process control module, specifically designed for demanding industrial automation and power generation applications. It serves as a key component in regulating complex processes such as turbine control, boiler management, and industrial process automation, enabling precise monitoring and adjustment of critical variables to ensure operational stability and efficiency. This module excels in processing real-time data from a wide range of sensors and field devices, executing advanced control algorithms, and issuing accurate commands to actuators like valves, pumps, and variable-speed drives. It is widely utilized in power plants, oil and gas facilities, and large-scale manufacturing plants, where reliable control of high-stakes processes is essential for maintaining safety, optimizing energy consumption, and minimizing downtime. With its robust construction and advanced features, it delivers consistent performance even in harsh industrial environments characterized by temperature fluctuations, vibration, and electrical noise.
Technical Parameters
- Processor: 32-bit microcontroller with a clock speed of 150 MHz, ensuring fast execution of complex control logic and real-time data processing.
- Memory: 2 MB RAM and 8 MB flash memory, providing ample storage for program code, data logging, and temporary data handling.
- Operating Voltage: 24 V DC ± 15%, compatible with standard industrial power supply systems.
- Power Consumption: Typical 20 W, balancing high performance with energy efficiency.
- Digital Inputs: 20 channels, supporting dry contact or 24 V DC signals, for monitoring the status of switches, sensors, and safety interlocks.
- Digital Outputs: 16 channels, relay outputs (NO/NC) with a maximum switching voltage of 250 V AC and current of 8 A, enabling control of heavy-duty actuators and alarms.
- Analog Inputs: 12 channels, 16-bit resolution, accepting 4 ~ 20 mA DC or 0 ~ 10 V DC signals, for precise measurement of process variables such as pressure, temperature, and flow.
- Analog Outputs: 6 channels, 16-bit resolution, providing 4 ~ 20 mA DC signals, for modulating control of valves and variable-speed drives.
- Communication Interfaces: 2 x RS485 ports (Modbus RTU), 1 x Ethernet port (10/100 Mbps, Modbus TCP/IP), facilitating seamless data exchange with PLCs, SCADA systems, and other control components.
- Operating Temperature Range: -10 ~ 60 °C, suitable for harsh industrial working environments.
- Storage Temperature Range: -40 ~ 85 °C, maintaining integrity during storage and transportation.
- Relative Humidity: 5% ~ 95% (non-condensing), resistant to moisture-related issues.
- Isolation: 2.5 kV galvanic isolation between I/O channels and power supply, enhancing system safety and reducing electromagnetic interference.
- Dimensions (L × W × H): 140 mm × 120 mm × 60 mm, compact for easy installation in control cabinets.
- Weight: Approximately 400 g, lightweight for convenient handling and mounting.
- Mounting Type: DIN rail mounting, compatible with standard industrial mounting systems.
- Certifications: CE, UL, IEC 61010, meeting international safety and quality standards for industrial control equipment.
The ABB PCD235A101 3BHE032025R0101 is available for global sale, covering all major industrial regions. Orders are processed promptly, with delivery guaranteed within 3 days, ensuring quick integration into your automation systems to minimize operational delays.
