ABB PFEA113-20 3BSE050092R20 Product Introduction
Product Description
The ABB PFEA113-20 3BSE050092R20 is a high-precision signal conditioner module, specifically designed to process and amplify signals from load cells and force transducers in industrial weighing and tension measurement systems. It converts weak analog signals from these sensors into standardized, stable outputs that can be easily interpreted by control systems, PLCs, or data acquisition devices. This module is widely used in industries such as material handling, metal processing, packaging, and automotive manufacturing, where accurate measurement of weight, tension, or force is critical for ensuring product quality, process efficiency, and operational safety. With its advanced signal processing technology and robust design, it minimizes the impact of electrical noise and interference, delivering reliable and consistent performance even in harsh industrial environments.
Technical Parameters
- Input Signal Type: Compatible with strain gauge-based load cells and force transducers (350 Ω nominal resistance).
- Input Range: ±20 mV/V, accommodating a wide range of sensor outputs.
- Output Signal: 4 ~ 20 mA DC and 0 ~ 10 V DC (selectable), compatible with standard industrial control systems.
- Accuracy: ±0.01% of full scale, ensuring highly precise signal conversion.
- Excitation Voltage: 10 V DC (nominal) for powering connected load cells, with a maximum current of 350 mA.
- Filtering: Adjustable low-pass filter (0.5 ~ 100 Hz) to reduce noise and stabilize signals.
- Operating Voltage: 24 V DC ± 10%, compatible with standard industrial power supplies.
- Power Consumption: Typical 3 W, ensuring energy-efficient operation.
- Operating Temperature Range: -10 ~ 60 °C, suitable for harsh industrial working environments.
- Storage Temperature Range: -40 ~ 85 °C, maintaining integrity during storage and transportation.
- Relative Humidity: 5% ~ 95% (non-condensing), resistant to moisture-related issues.
- Isolation: 2.5 kV galvanic isolation between input, output, and power supply, enhancing system safety and reducing interference.
- Dimensions (L × W × H): 100 mm × 75 mm × 50 mm, compact for easy installation in control cabinets.
- Weight: Approximately 150 g, lightweight for convenient handling and mounting.
- Mounting Type: DIN rail mounting, compatible with standard industrial mounting systems.
- Certifications: CE, UL, ensuring compliance with international safety and performance standards.
The ABB PFEA113-20 3BSE050092R20 is available for global sale, covering all major industrial regions. Orders are processed promptly, with delivery guaranteed within 3 days, ensuring quick integration into your weighing or tension measurement systems to minimize operational delays.
