Operating Temperature Range:-40°C to +85°C
Input Voltage Rating:Up to 1200V AC
Current Handling Capacity:1200A
Thermal Resistance:≤ 30°C/W
Insulation Resistance:≥ 100MΩ @ 500V DC
Electrical Lifetime:Over 10 million switching cycles
Protection Class:IP20
Operating Humidity Range:5% to 95% non-condensing
The SIEMENS 6DD2 920-3AW1 Thyristor Electronics is a robust solution for controlling large power systems in various industries. It features advanced thyristor technology that ensures efficient power conversion and distribution, making it ideal for applications requiring high voltage and current handling capabilities.
Designed with precision and reliability in mind, this module boasts an operating voltage of 400V and a current rating of 60A, capable of meeting the demands of even the most demanding industrial settings. Its air-cooled design optimizes heat dissipation, ensuring continuous and stable performance under a wide temperature range from -40°C to +85°C.
Equipped with a single SPST relay output, it provides a fail-safe mechanism for critical control functions, ensuring system integrity and safety. The insulation resistance exceeding 100 MΩ at 500V DC ensures a high level of electrical isolation, enhancing the overall safety and efficiency of the system.
With its compact dimensions of 120 x 75 x 50 mm and a lightweight structure weighing only 0.5 kg, this module is easy to integrate into existing systems without compromising on performance. The inclusion of CE and UL certifications guarantees compliance with international safety standards, offering peace of mind to users.
Ideal for applications in power distribution, motor control, and other industrial control systems, the SIEMENS 6DD2 920-3AW1 Thyristor Electronics is a versatile component that delivers superior performance and reliability, making it a preferred choice for engineers and technicians worldwide.
