SIEMENS 6ES7314-1AE04-0AB0: CPU 314 Central Processing Unit

Core Processing Speed:20 MHz

Memory Capacity:24 KB program + 750 KB data

Input/Output Channels:16 Digital Inputs (DI) + 16 Digital Outputs (DO)

Analog Input Channels:4

Analog Output Channels:1

Power Supply:24 V DC

Operating Temperature Range:-25°C to +60°C

Communication Interface:MPI Multi-Point Interface

    The SIEMENS 6ES7314-1AE04-0AB0 CPU 314 Central Processing Unit is engineered to deliver exceptional performance in a compact size, making it ideal for space-constrained industrial applications. This CPU boasts an integrated 24 V DC power supply, ensuring reliable operation without additional hardware. With 24 KB of work memory, it provides ample storage for complex programming tasks, enhancing system efficiency.

    Equipped with 16 digital inputs (DI) and 16 digital outputs (DO), along with 4 analog inputs (AI) and 1 analog output (AO), the CPU 314 offers flexible connectivity options, supporting a wide range of sensors and actuators. The integrated I/O channels significantly reduce the need for external modules, simplifying installation and maintenance.

    Designed for seamless integration with SIMATIC Step 7 software, this CPU ensures easy programming and configuration, facilitating quick setup and customization for diverse industrial environments. Its robust design and compatibility with various fieldbus protocols make it a versatile choice for modern automation systems.

    The CPU 314’s compact footprint and modular design allow for easy expansion and upgrade, making it a future-proof solution for evolving industrial needs. Whether it’s for machinery control, process automation, or production line optimization, this CPU delivers high reliability and performance, backed by SIEMENS’ commitment to quality and innovation.

    To further enhance system stability and efficiency, the CPU 314 features built-in EMI filtering, safeguarding against electrical interference and ensuring smooth operation in challenging industrial settings. Its comprehensive protection measures and support for DC BUS sharing contribute to its reliability, making it an indispensable component in any industrial control system.
